Technical specs sequence
Review each specification block in sequence, then open the full section below.
System Types
Choose passive sacrificial (no power, annual anode) or active ICCP (120/240V, reference electrode, ~10-year controller) based on size, environment, and monitoring needs.
Jump to system types
Sacrificial Anode Specifications
Magnesium anode ~−1.6 V vs copper, stainless clamp, suction-line mount, $40–$60 anodes, ~30-minute install, annual swap, no refrigerant work.
Jump to sacrificial specs
ICCP System Specifications
Titanium anode, auto current control, real-time reference electrode feedback, ~10-year controller life, ~$500 system, optional BAS logging.
Jump to ICCP specs
Universal Compatibility
Major residential and commercial brands; aluminum, copper, and mixed coils; condensers and mini-splits; unusual tonnage or process loads—confirm with us first.
Jump to compatibility
Warranty and Support
CoilShield warranties cover our hardware and install expectations; they do not replace OEM equipment warranty. Ask for sizing help with tonnage, coil type, and environment.
Jump to support detailsComplete technical specifications for CoilShield protection systems.
System Types
Two protection approaches are available. The right one depends on system size, environment, and whether active monitoring is required.
Sacrificial Anode Specifications
Anode material: Magnesium. Electrochemical potential: Approximately -1.6 V relative to copper. Mounting hardware: Stainless steel clamp, included. Power required: None. Installation point: Suction line (metallic contact). Replacement interval: Annual at routine HVAC service visit. Residential anode cost: $50 per anode. Minisplit anode cost: $40 per anode. Commercial anode cost: $60 per anode. Installation time: Approximately 30 minutes. Refrigerant handling: Not required. System modification: None.
Full dimensional specifications and hardware drawings are available; contact us for product documentation.
ICCP System Specifications
Anode material: Inert titanium. Power supply: 120V or 240V AC. Monitoring: Reference electrode, real-time. Current adjustment: Automatic (controller-managed). Controller service life: Approximately 10 years. Installation: Professional installation required. System cost: $500. BAS integration: Available (logging and alert output). Refrigerant handling: Not required. System modification: None.
Full controller specifications, wiring diagrams, and reference electrode installation details are available; contact us for product documentation.
Universal Compatibility
Both systems are compatible with aluminum coils, copper coils, and mixed-metal evaporator and condenser coils. They work with every major residential and commercial HVAC brand, including Carrier, Lennox, Trane, Goodman, Daikin, Mitsubishi, and Fujitsu. No modifications to the refrigerant circuit, electrical system, or coil assembly are required. If your application is unusual (large tonnage, multi-circuit, or process cooling), contact us before purchasing and we will confirm compatibility and sizing.
Compatibility summary: Aluminum evaporator: Yes. Copper evaporator: Yes. Mixed-metal (copper tube / aluminum fin): Yes. Condenser coil: Yes. Mini-split (indoor and outdoor): Yes. Commercial rooftop unit: Yes.
Warranty and Support
Sacrificial Anode System: Materials and workmanship warranty. Anode replaced annually as part of routine HVAC service. No service interruptions required between annual visits under normal operating conditions.
ICCP System: Professional installation warranty plus comprehensive system warranty. Controller service life approximately 10 years. Extended service agreements available for critical applications.
CoilShield protection does not replace or extend the HVAC manufacturer's equipment warranty. It is a maintenance measure designed to prevent coil failure before it occurs.
Questions about sizing or compatibility? Contact us for a consultation. Include your system tonnage, coil type, and environment (coastal, agricultural, industrial, or standard residential).
